LONGFIAN JAY-5AW Medical Oxygen Concentrator – 5L Home & Clinical Oxygen Therapy

The LONGFIAN JAY-5AW Medical Oxygen Concentrator is a reliable, high-performance oxygen therapy device designed for both homecare and clinical environments. It delivers a continuous oxygen flow of up to 5 liters per minute (LPM) with a stable oxygen concentration of 93% ±3%, ensuring dependable respiratory support for patients requiring long-term oxygen therapy.

Designed with advanced molecular sieve technology, the JAY-5AW operates quietly at ≤40 dB, providing a comfortable and peaceful environment for patients. Its compact footprint and lightweight construction make it easy to position in homes, clinics, nursing facilities, and healthcare centers.

Features

• Continuous oxygen flow up to 5 LPM
• Stable oxygen purity of 93% ±3%
• Quiet operation (≤40 dB)
• Built-in nebulizer (atomization) function
• Large, easy-to-read LCD display
• Intelligent alarm system for enhanced safety
• Compact, space-saving design
• USA-imported humidifier with 6 PSI pressure relief
• Optional pulse oximeter support
• Suitable for homecare, clinics, hospitals, and nursing facilities

Technical Specifications

• Model: LONGFIAN JAY-5AW
• Flow Rate: 0–5 LPM
• Oxygen Purity: 93% ±3%
• Outlet Pressure: 0.04–0.07 MPa (6–10 PSI)
• Noise Level: ≤40 dB
• Power Consumption: ≤350 W
• Dimensions: 348 × 280 × 510 mm
• Net Weight: 16 kg

The LONGFIAN JAY-5AW Oxygen Concentrator offers dependable oxygen delivery, intelligent monitoring, and user-friendly operation, making it an excellent solution for patients requiring continuous oxygen therapy with professional-grade performance.

Medical Oxygen Concentrator

The unit features a large LCD display that provides real-time operating information, including working pressure, accumulated operating hours, current runtime, switch count, and programmable timer settings from 10 minutes to 40 hours. Intelligent safety alarms notify users of power failure, high or low pressure, low oxygen purity, low flow, and high temperature, enhancing operational safety and reliability.

An integrated nebulizer (atomization) function allows respiratory medication delivery without requiring an additional device, making it ideal for patients needing both oxygen therapy and nebulization. The concentrator also supports an optional pulse oximeter for convenient oxygen saturation monitoring.

Powered by an energy-efficient motor with a maximum power consumption of 350W, the JAY-5AW combines performance with economical operation. Its USA-imported humidifier and 6 PSI pressure relief system improve user comfort while maintaining safe oxygen delivery.
